2022 Paper cup Making Machine PE Laminated Paper cup 7oz

Name: 2022 Paper cup Making Machine PE Laminated Paper cup 7oz
Brand: Novery
Price: 11 USD

China 2022 Paper cup Making Machine PE Laminated Paper cup 7oz wholesale

Applicable Industries : Hotels, Home Use, Food & Beverage Shops

Showroom Location : Saudi Arabia, Russia, South Korea, Romania

Condition : New

Product Type : Paper Bowl Machine

Processing Type : Paper Folding Machine

Place of Origin : China

Brand Name : Novery

Voltage : 380V/220V

Power : 8kw

Dimension(L*W*H) : 2900*1300*1800

Weight : 2000 kg

Warranty : 1 Year

Production Capacity : 50-60 pcs per min

Machinery Test Report : Not Available

Video outgoing-inspection : Provided

Marketing Type : New Product 2021

Warranty of core components : 1 Year

Core Components : PLC, Bearing

Speed : 50-60 Pcs/min

Finished Products : Paper bowl

Keyword : paper bowl making machine

Raw material : PE Laminated paper

Relay : Chnt

Certification : ce

After-sales Service Provided : Free spare parts

Packaging Details : standard export packing

Port : ningbo or shanghai

Supply Ability : 100 Set/Sets per Month

Price : $11,000.00/sets 1-1 sets

Contact Now

2021 newest high speed intelligent paper bowl making machine

Introduction:

ZW-A40 is an newest type of paper bowl machine, by auto feeding paper with multiple rows, paper anti- reverse device( make sure correct position), ultrasonic welding, oil fill, robot arm, paper tube, punch bottom, folding bottom, pre-heating, knurling, curling, and drop cups. Machine can make various size of bowls by changing mould. This model is invented by our team and widely improved by technique.

2022 Paper cup Making Machine PE Laminated Paper cup 7oz

Product Features:

1. More productivity. ZW-A40 model paper bowl machine with 50-60pcs/min speed, which isdeveloped from with 30-40pcs/min, but electricity consumption is remained to be 4.8kw with higher productivity.

2. This model dimension is special designed to be smaller than before, so the construction is more compact and the working process is simpler. To change the 3 plates to 1 plate system, by adding a small plate for dropping cups, which is very convenient and easy.

3. The bottom cutter is under the mould to make sure directly punch cup bottom after the bottompaper cutting, so it can avoid cup to be turned over.

4. The paper curling adopts a separate cam, then the stroke of the lifting plate is greatly reduced and the vibration of the machine is reduced, so as to improve stability.

5. With the device PLC of non-touch multi-point light control button(in papertube, paper roll,paper dropping place as so on) to detect working fault, machine can automatically stop running with alarm. It can avoid machine parts friction to improve machine stability and lifespan.

6. Hold tube Station is driven by 3-into-1 Cam system, which can work voiceless and more stably. This is leading technology in China.

2022 Paper cup Making Machine PE Laminated Paper cup 7oz

MODEL	ZW-A40 Paper Bowl Machine
FOB PRICE	11500USD
Extra mould charge	900USD
Weight	2000KG
Size	2600x1300x1600mm
Voltage	380V,4.8KW (3 phrase)
Working Speed	50-60pcs/min
Paper specification	Single PE/ Double PE
Paper Weight	150-350gsm
Paper Cup Size	(A)φ100- 135mm	(B)φ50-110mm
Paper Cup Size	(C)φ80-110mm	(D)φ5-8mm
Machine Configurati on	Ultrasonic	Wenzhou
	Transducer	Huifeng
	PLC	Mitsubishi
	Touch Screen	Taiwan
	Motor	China-Changzhou
	Main Motor	China- Shanghai
	Curling Motor	China- Shanghai
	Drive Shaft	40CR
	Linear axis	Hard Axis
	Intermittent slitter	China- Shangdong

Mould/Knurling

CR12 Quench/ 40CR NITRIDING

Turntable

Aluminium alloy

2022 Paper cup Making Machine PE Laminated Paper cup 7oz

2022 Paper cup Making Machine PE Laminated Paper cup 7oz Images
